DC Power Generator is an outdoor -48VDC standby generator designed to support telecommunications network power through extended utility power outages. Using naturally aspirated compact package engine, it’s powerful but quiet.DC Power Generator installation and deployment is quicker, easier and less costly than a traditional AC generator. Its availability can be assured through remote web browser access as well as M2M automation using SNMP alarms, polling and exercise.
Features:
- Available in 10kW, 52VDC, positive ground.
- Easy installation and maintenance.
- Delivered to a roof by elevator and stairs. Low weight minimizes civil costs.
- DC output design reduces space requirements for generator and large batteries. Increases efficiency and reliability over an AC generator.
- 9-phase alternator and extensive LC filtering for clean output.
- Connects directly to DC plant with no need for a transfer switch or any AC power modifications.
- Diffused and diluted exhaust without any hot surfaces. Cabinet is safe to touch.
- Easy Integration with renewable energy systems.
- Automatic operation, triggered on loss of AC utility power digital input and/or and battery voltage thresholds.
- WEB browser interface for programming, control, monitoring, and firmware updates.
- SNMP Traps containing configurable alarm names and severities to respect Control Center standards. Generous alarm contacts are provided for traditional monitoring.
- Safe Voltages for Telco Network Power Technicians troubleshooting.
Specifications
- Rated Power: 10 kW @ 52 VDC
- Output Voltage: -52 VDC
- Engine type: Air Cooled
- Fuel consumption 100% load: LPG: 9.48 lbs/h, NG : 8.88 lbs/h
- Dimensions (W x H x D): 1155 x 1155 x 770mm (45.5 x 45.5 x 30.3in)
- Weight: 227kg (<500lb)
- Operating temperature: -30℃ to +50℃ (-34℉ to +122℉)
- Acoustics: ≤ 65dBA @ 23ft (7m)
- Safety: UL/cUL
- EMI (radiated/conducted): FCC Part 15 Class A and ICES-003
- Environment: RoHS
