RKTPL enables you to deploy a stand-alone operational cellular network in less than three minutes. This product combines all of the key elements in a cellular network into a single system that is easy to transport and carry. Integration with any external networks can also be supported.A ruggedized enclosure houses all the necessary components of a cellular network.System is capable of supporting voice, data and SMS and video services. A Wi-Fi interface enables the system operator to manage its group of users via PC, laptop or tablet computer. The GUI interface is simple and easy to use. Groups of phones can be set up for push-to-talk communications, group calling and text messages. Additionally, system operators can send text messages from the GUI to the users. These features make the system an excellent field communications tool.

Applications and Deployment Scenarios

  • First Responder Communications
  • Emergency Cellular Networks
  • Rapid Deployment in Remote Areas or for Disaster Relief
  • Tactical Military Communications
  • Temporary Cellular Networks for Industry
  • Private Push-to-talk Mobile Networks

System Features

  • Voice, SMS/text, data services
  • Coverage up to 3 kilometers
  • SMS to individual, group or broadcast via Web GUI
  • Easy integration with external networks

Call Management Features

  • Individual & Group voice call & text messaging
  • Individual & Group push-to-talk
  • Dispatch console, broadcast text messaging
  • Call Forwarding, Call Waiting, Three way calling
  •  System, group and individual based user dial plans
  • Inbound / Outbound call restrictions

Technical Specifications

  • Configuration Details Technology Supported:GSM/3G CDMA2000/3G UMTS (W-CDMA)/4G LTE
  • Interfaces:Ethernet / RJ-45 ,USB ,WiFi
  • Dimensions: 43 cm H × 30 cm W x 11 cm D
  • Weight:13 Kg
  • Input Voltage:12 – 35 VDC
  • Power Consumption:90 W typical operating
  • Options Battery Pack Module: ( 7 Kg )
  • Backpack Frame Kit
  • Temperature Operating: -40 to +50°C
  • Storage: -40 to +75°C**
  • Web Console : GUI

For Further Information

Please Contact Us for more information.
